Purpose

This dashboard show the Order Entry statistics by Visibility Point. Please see the Common Use Cases section in Beeks Document BKDA004 VMX-Explorer User Guide for an example of use.

Order Entry Stats By VP dashboard.

Instructions for use

Switch between VPs and select which Gateways to view. Select the time period from the Time Picker at the top.

Panel overview

The Summary panels are:

  • Flow by Gateway

  • Message Count by Gateway

  • Roundtrip by Gateway/Interval

  • Roundtrip by Gateway

  • RX Wiretime By Gateway

The Message Type Breakouts Per Line panels show the following for each Gateway:

  • Message Rate By Message Type

  • Roundtrip By Message Type

The Latency Percentiles By Gateway panels are:

  • Roundtrip Percentiles

  • Roundtrip Percentiles By Message Type

The RX Wiretime Percentiles per Gateway panels are:

  • Rx Roundtrip Percentiles as a line graph showing Maximum, Mean, 99th, 95th, and Minimum.

  • Rx Roundtrip Percentiles as a bar chart showing Maximum, Average, 99th, 95th, and Minimum.

The Moving Average Latency By Session panels show the following for each VP:

  • Moving Average Latency By Session

  • Moving Average Latency By Session by Message Type
